ASTM A283 Grade C Plates

Product Description:
ASTM A283 Grade C Plates are standard specification structural steel plates with intermediate tensile strength, primarily used in general fabrication and construction applications. These plates offer excellent weldability and formability, making them suitable for structural frameworks, tanks, equipment bases, and pressure vessel fabrication.

Key Features:

• Moderate tensile strength with excellent ductility

• Good formability and machinability

• Superior weldability with all standard methods

• Affordable solution for general structural applications

• Reliable for low and moderate temperature service

Specifications:

• Grade: ASTM A283 Gr.C

• Thickness: 3mm – 150mm

• Width: 1000mm – 3000mm

• Length: 3000mm – 12000mm

• Finish: Hot Rolled / Pickled & Oiled

• Form: Plates, Sheets, Coils (on request)

Chemical Composition (% Max):

• Carbon (C): 0.24%

• Manganese (Mn): 0.90%

• Phosphorus (P): 0.035%

• Sulfur (S): 0.040%

Mechanical Properties:

• Tensile Strength: 380 – 515 MPa

• Yield Strength (Min): 205 MPa

• Elongation: ≥ 20% (in 200mm)

• Hardness: ≤ 135 HB (typical)

Applications:

• Structural Steel Fabrication

• Base Frames and Supports

• Storage Tanks and Pressure Vessels

• Bridges and Construction Equipment

• Boiler and Heat Exchanger Components

• Pipelines and Conveying Systems

Standards & Equivalents:

• ASTM: A283 Grade C

• ASME: SA283 Grade C

• EN Equivalent: S275JR (approx.)

• IS Equivalent: IS 2062 E250

Processing Services Offered:

• Shearing, Cutting, and Bending

• CNC Profiling / Plasma Cutting

• Surface Coating & Galvanizing

• Custom Lengths & Widths Available

Country of Origin:
India | Japan | Europe | Korea
