Industrial Sheets & Plates

Product Description:
Mild Steel Plates, also known as MS Plates, are low carbon steel plates known for their strength, workability, and cost-effectiveness. These plates are widely used across industrial and commercial sectors due to their excellent weldability, machinability, and high tensile strength. Mild steel plates provide a reliable solution for structural and general engineering applications.

Key Features:

• Low Carbon Content – Ideal for easy fabrication and forming

• Excellent Weldability – Perfect for structural joining and fabrication

• High Ductility & Toughness – Ensures durability under stress

• Corrosion Resistance – Can be coated or galvanized for extended life

• Versatile Applications – Suitable for various sectors from construction to shipbuilding

Specifications:

• Material Grade: IS 2062, ASTM A36, EN 10025

• Thickness: 1.5mm – 200mm

• Width: 500mm – 3000mm

• Length: 1000mm – 12000mm

• Surface Finish: Hot Rolled (HR), Cold Rolled (CR), Galvanized (GI)

• Form: Plain Sheet, Chequered Plate, HR/CR Coils

Mechanical Properties:

• Yield Strength: 240 – 410 MPa

• Tensile Strength: 410 – 560 MPa

• Elongation: 20% – 25%

• Hardness: ≤200 BHN (Typically)

Chemical Composition (% max):

• Carbon (C): ≤ 0.25%

• Manganese (Mn): ≤ 1.50%

• Sulphur (S): ≤ 0.050%

• Phosphorus (P): ≤ 0.050%

Applications:

• General Fabrication

• Construction (Beams, Columns, Platforms)

• Shipbuilding & Automotive

• Boilers & Pressure Vessels

• Tanks, Silos, Pipelines

• Railway Cars, Industrial Machinery

Processing Services Offered:

• Plasma/Laser/Flame Cutting

• Shearing & Bending

• Surface Coating & Galvanizing

• Machining & Drilling

• Custom Shapes & Sizes Available

Standards & Grades Available:

• Indian Standards: IS 2062 Gr A / B / E250 / E350

• American Standards: ASTM A36 / A283

• European Standards: EN 10025 S235JR / S275JR / S355JR

Country of Origin:
India | Japan | Korea | Europe | UAE

Product Overview:
S355J2 N Plates are high-strength structural steel plates with excellent toughness, weldability, and machinability. With low carbon content and a normalized delivery condition, these plates are widely used in heavy-duty structural and engineering applications. The "N" denotes that the plate is supplied in a normalized condition, enhancing its mechanical performance and structural reliability.

Key Features:

• Superior strength and impact resistance

• Excellent weldability and formability

• Performs well at sub-zero temperatures (Charpy impact at -20°C)

• Supplied in a normalized condition for enhanced durability

• Conforms to EN 10025-2 standard

Specifications:

Mechanical Properties:

• Yield Strength (Min):

  • ≤16mm: 355 MPa

  • 16mm: 345 MPa

• Tensile Strength: 470 – 630 MPa

• Elongation: ≥ 19%

• Impact Strength: 27J at -20°C (Charpy V-Notch)

Chemical Composition (Typical %):

Applications:

• Offshore structures and platforms

• Construction and heavy civil engineering

• Bridges and infrastructure

• Mining and Earthmoving machinery

• Pressure vessels and boilers

• Wind towers and turbine bases

Available Services:

• Cutting (Plasma/Oxy)

• Bending & Forming

• Drilling & Machining

• Shot Blasting & Primer Coating

• Ultrasonic Testing (UT) & Visual Inspection

Leading Brands / Origins:

• SAIL, ESSAR, JSPL (India)

• Dillinger, ThyssenKrupp (Germany)

• ArcelorMittal (Europe)

• SSAB (Sweden)

Product Overview

ASME SA 516 GR.60 Plates are high-quality pressure vessel steel plates designed for moderate- to low-temperature service. Manufactured with excellent weldability and notch toughness, these plates are ideal for fabricating pressure vessels and boilers in industries such as oil & gas, petrochemical, chemical, and power generation.

Key Features

• Excellent notch toughness

• Superior weldability

• Reliable performance under pressure

• Ideal for moderate/low temperature conditions

• Available with NACE MR0103/MR0175 compliance

Specifications

Mechanical Properties

Chemical Composition (% Max)

Traces of Cr, Cu, Ni, Mo, Nb, Ti, V ≤ 0.3–0.08% may be present based on specification.

Available Heat Treatment Conditions

• As Rolled (AR)

• Normalized (N)

• Normalized + Tempered (N+T)

• Quenched + Tempered (Q+T)

Applications

• Pressure Vessels

• Heat Exchangers

• Industrial Boilers

• Storage Tanks

• Refinery Equipment

• Oil & Gas Process Equipment

Would you like to add SA 516 GR.60N, GR.70, or dual-grade plates to this listing? I can also generate a comparison table or export-ready PDF if required.

Quenched and Tempered (Q&T) steel plates are high-strength, toughened steel plates manufactured through a two-stage heat treatment process: quenching (rapid cooling) followed by tempering (controlled reheating). This process significantly enhances the plate’s strength, hardness, impact resistance, and toughness.

These plates are widely used in structural and pressure vessel fabrication, mining equipment, construction machinery, military armor, bridges, and offshore structures, especially where weight reduction without compromising strength is essential.

• High yield and tensile strength

• Superior impact resistance and crack arrest capability

• Excellent toughness, even at low temperatures

• Good formability and weldability (depending on grade)

• Ideal for weight-sensitive, high-load applications

Higher grades like S890QL and S960QL offer even higher strength values.

• Ultrasonic Testing (UT) – As per EN 10160 / ASTM A578

• Charpy Impact Testing (at -20°C, -40°C or -60°C)

• Hardness Testing (Brinell or Rockwell)

• Chemical Analysis, PMI, Spectro Test

• Flattening / Bending / Tensile Test

• Third-Party Inspection – TUV, DNV, Lloyds, BV, SGS

• High-strength mobile and lifting equipment

• Offshore oil and gas structures

• Construction cranes and bridges

• Military vehicles and armor plating

• Heavy earth-moving and mining equipment

• Pressure vessels and welded tanks (in select grades)

• Mill Test Certificate – EN 10204 3.1 / 3.2

• Impact Testing Report

• Ultrasonic Testing Report

• Heat Treatment and Mechanical Test Records

• Full Traceability and Third-Party Inspection (on request)

Would you like:

• A comparison between Q&T steel and normalized steel plates?

• A PDF brochure with product images and specifications?

• Export packing and delivery details?

Alloy steel plates are engineered with a combination of alloying elements like chromium, molybdenum, nickel, manganese, vanadium, and boron, which enhance the steel’s mechanical strength, toughness, heat resistance, and corrosion resistance. These plates are widely used in boilers, pressure vessels, heat exchangers, power plants, offshore structures, oil & gas pipelines, mining machinery, and heavy engineering applications.

Available in a wide range of grades and specifications, alloy steel plates offer high performance in elevated temperature and high-pressure environments.

• Excellent high-temperature strength

• Superior corrosion and oxidation resistance

• Enhanced toughness and impact resistance

• Suitable for welding, bending, and forming

• Available in quenched & tempered, normalized, or annealed conditions

• Ultrasonic Testing (UT) – EN 10160 / ASTM A578

• Impact Testing (Charpy V-notch)

• Tensile & Bend Testing

• Chemical & Hardness Testing

• Third-party Inspection – TUV, DNV, Lloyd’s, SGS (upon request)

• Pressure vessels and boilers

• Heat exchangers and refinery tanks

• Steam lines and high-temperature pipelines

• Offshore platforms and petrochemical units

• Mining and earth-moving equipment

• Power generation and thermal plants

• Mill Test Certificate – EN 10204 3.1 / 3.2

• Ultrasonic and Impact Test Reports

• Chemical and Mechanical Test Results

• Third-party inspection certificates

• Full traceability and QA/QC records

Abrasion Resistant (AR) Steel Plates are specially designed to withstand extreme wear and tear, impact, and sliding abrasion. These plates are commonly used in mining, construction, quarrying, cement, recycling, and earthmoving equipment. Their high hardness, excellent toughness, and superior wear life help reduce maintenance downtime and increase productivity.

Available in different hardness grades like AR400, AR450, AR500, AR600, and proprietary grades (e.g., Hardox®, JFE-EH, Quard®, etc.), these plates offer excellent durability in harsh environments.

• Exceptional resistance to abrasion and wear

• High surface hardness (up to 600 BHN)

• Maintains good formability and weldability

• Reduces maintenance frequency and downtime

• Suitable for impact-heavy and sliding abrasion applications

• Mining equipment (buckets, liners, screens)

• Earthmoving and excavation tools

• Cement and aggregate plant wear parts

• Truck beds, hoppers, and dump bodies

• Shot blasting machines and armor plating

• Recyclers, shredders, and conveyor systems

• Compatible with shielded metal arc welding (SMAW), GMAW, and FCAW

• Recommended preheat for thicker sections to prevent cracking

• Can be cut using plasma, oxy-fuel, or laser

• Cold forming possible with appropriate radii and slow bend rates

• Mill Test Certificates – EN 10204 3.1 / 3.2

• Chemical Composition & Hardness Test Reports

• Dimensional & Ultrasonic Test Reports (on request)

• Third-party inspection reports (if needed)

Weather-Resistant Corten Steel Plates | ASTM A588 / A242 | Corten A & Corten B Plate Supplier & Exporter in India

Corten Steel Plates, also known as weathering steel, are high-strength, corrosion-resistant plates that develop a protective rust-like appearance over time. This unique weathered look makes them ideal for architectural, structural, and outdoor applications without the need for painting or coating.

Corten Steel is primarily available in two grades – Corten A (ASTM A242) and Corten B (ASTM A588) – each offering superior resistance to atmospheric corrosion, especially in industrial and urban environments.

• Grades: Corten A (ASTM A242), Corten B (ASTM A588)

• Standards: ASTM A588 / A242, EN 10025-5

• Thickness: 1.5 mm – 100 mm

• Width: Up to 2500 mm

• Length: 2000 mm – 6000 mm or customized

• Finish: Hot Rolled, Rusted, Pickled, or Clean Surface

• Form: Plates, Sheets, Coils, Flats

• Self-protecting weather-resistant oxide layer

• Eliminates need for painting in most environments

• High strength and durability

• Excellent workability and weldability

• Low maintenance and long life

• Aesthetic rusted appearance ideal for architecture

• Bridges and Highway Structures

• Railway Cars and Containers

• Outdoor Sculptures & Art Installations

• Building Facades and Roof Panels

• Garden and Landscape Design

• Chimney Liners and Flue Gas Systems

• Architectural Cladding & Signage

• Corten A & Corten B Steel Plates

• Perforated Corten Steel Sheets

• Weathering Steel Coils

• Decorative Corten Flats and Panels

• Laser-Cut Corten Components
