500 Kilogram (MOQ)
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Trader, Distributor, Importer |
| Type | Steel Plates |
| Material | Quenched And Tempered Steel |
| Strength | High Yield And Tensile Strength |
| Click to view more | |
Product Details
Quenched and Tempered (Q&T) steel plates are high-strength, toughened steel plates manufactured through a two-stage heat treatment process: quenching (rapid cooling) followed by tempering (controlled reheating). This process significantly enhances the plate’s strength, hardness, impact resistance, and toughness.
These plates are widely used in structural and pressure vessel fabrication, mining equipment, construction machinery, military armor, bridges, and offshore structures, especially where weight reduction without compromising strength is essential.
Key Features-
High yield and tensile strength
-
Superior impact resistance and crack arrest capability
-
Excellent toughness, even at low temperatures
-
Good formability and weldability (depending on grade)
-
Ideal for weight-sensitive, high-load applications
| Grades Available | S690QL, S890QL, S960QL, ASTM A514 Gr. B / Q / F / H, A517 |
| Thickness | 6 mm – 150 mm |
| Width | 1000 mm – 3500 mm |
| Length | 3000 mm – 12000 mm |
| Condition | Quenched & Tempered |
| Surface Finish | Mill Finish / Shot Blasted / Painted (optional) |
| MOQ | 10 Metric Tons |
| Delivery Time | 7 – 15 Working Days |
| Yield Strength | ≥ 690 MPa |
| Tensile Strength | 770 – 940 MPa |
| Elongation | ≥ 14% (in 5d) |
| Impact Toughness | ≥ 27 J at -40°C |
Higher grades like S890QL and S960QL offer even higher strength values.
Testing & Quality Assurance-
Ultrasonic Testing (UT) – As per EN 10160 / ASTM A578
-
Charpy Impact Testing (at -20°C, -40°C or -60°C)
-
Hardness Testing (Brinell or Rockwell)
-
Chemical Analysis, PMI, Spectro Test
-
Flattening / Bending / Tensile Test
-
Third-Party Inspection – TUV, DNV, Lloyds, BV, SGS
-
High-strength mobile and lifting equipment
-
Offshore oil and gas structures
-
Construction cranes and bridges
-
Military vehicles and armor plating
-
Heavy earth-moving and mining equipment
-
Pressure vessels and welded tanks (in select grades)
-
Mill Test Certificate – EN 10204 3.1 / 3.2
-
Impact Testing Report
-
Ultrasonic Testing Report
-
Heat Treatment and Mechanical Test Records
-
Full Traceability and Third-Party Inspection (on request)
